Vision Avr Generator Parts Gavr-15c Voltage Regulator Avr Gavr15a Gavr10b Brushless Avr

Product Description





Automatic Voltage

Regulator Brushless
AVR GAVR 15C

AVR Automatic Voltage Regulator Circuit Diagram GAVR-15C is a half-wave phase controlled thyristor type Automatic Voltage Regulator and forms part of the excitation system for a brushless generator. In addition to regulating the generator voltage, the AVR circuitry includes under speed and sensing loss protection to ensure safe, reliable control of the generator. Positive voltage build up from residual levels is ensured by the use of proficient

Product name
GAVR-15C

Sensing/Power input
Voltage
220V
Frequency
50-60HZ nomina
Phase
1

Magnetic Field Output
Resistance
15 ohms minimun
Current
Max 10A ,Continuous 7A for 10 seconds
PRESSURE REGULATING ACCURACY
<±1% RMS with 4% engine governing
 Function

 – Positive voltage build up from residual levels is ensured by   the use of proficient semiconductors in the power circuitry of   the AVR. Which is linked with the main stator windings and   the exciter field windings to offer closed loop control of the   output voltage with load regulations of ± 1.5%.

  Advantage

  – In addition to regulating the generator voltage, the AVR     circuitry includes under speed and sensing loss protection to   ensure safe, reliable control of the generator.


Performance

-Factory used the advanced equipment to produce, assembly and inspect.

-To ensure the high accuracy.

-And the HD panel used to make everything showed clear.

 -10 years production experiences,over 10 times the mold improved, makes the body and parts in perfect match.

– Nice outside and strong inside.
