Hot Sales Electrical Changeover Switches Ats 2000a Automatic Transfer Switch 3200a 2500a 1600a 1250a 1000a For Diesel Engine

Product Description
VISION ATS Automatic Transfer Switch

20A 63A 80A 100A 125A 160A 250A 400A 630A 800A
1000A 1250A 1600A 2000A 2500A 3200A

When the mains power fails or is in an abnormal state such as phase loss, overvoltage, or undervoltage, the ATS system
automatically starts the standby diesel generator set according to the preset mains loss confirmation delay. After confirming that
the output voltage of the generator set is normal, it automatically switches to For the generator set, the load is powered by the
generator set; when the mains power returns to normal, it will automatically switch to restore the mains power supply to the load
after confirmation by a preset delay. After the generator set is unloaded, it will automatically stop after a preset cooling operation.

Main Technology Parameters

Recommended Cabinet Installation Dimension

Model

Recommended Cabinet Dimension (L*W*H cm)

Recommended Cabinet Dimension (L*W*H cm)

VSQ3-100A-VSQ3-250A

50*40*80

50*25*60

VSQ3-300A-VSQ3-630A

60*50*180

55*45*160

VSQ3-800A -VSQ31250A

80*60*220

75*60*180

VSQ3-1600A

80*60*220

75*60*200

VSQ3-2500A-VSQ3-3200A

80*80*220

75*80*200

Reference only ,please according to the actual conditions.
Product name

Net weight(KG)

DIMENSION/SET (cm)

QTY/ CTN

G.W./ CTN

N.W./ CTN

DIMENSION/CTN(CM)

PACKING TYPE

4

28*12*17

6

22.5

21.5

38.5*30*37







CARTON

7

34.5*21.5*23

2

14

13

45.5*37.5*25.5

7

34.5*21.5*23

2

14

13

45.5*37.5*25.5

9.5

42*21.5*26

2

19

18

46.5*45*29

17.5

53*30*33.5

1

17.5

16.5

53*30*33.5

17.5

53*30*33.5

1

17.5

16.5

53*30*33.5

18.5

53*30*33.5

1

18.5

17.5

53*30*33.5

18.5

53*30*33.5

1

18.5

17.5

53*30*33.5

47.5

72*40*39

1

47.5

41.5

72*40*39






PLY WOOD CASE

47.5

72*40*39

1

47.5

41.5

72*40*39

50

72*40*39

1

50

44

72*40*39

52.5

72*40*39

1

52.5

46.5

72*40*39

108

74*44*50

1

105

108

74*44*50

111

74*44*50

1

107

111

74*44*50

113

74*44*50

1

109

113

74*44*50

STACKING:

NO more 5 layers for 630a and below and no more than 3 layers for 800a and above
