Product Description
HAT700BI
HAT700 series ATS controller is intelligent dual-supply module with configurable function, automatic measurement, LCD display, and digital communication. It combines digital, intelligence and networking. Automatic measurement and control can reduce incorrect operation. It is an ideal option for ATS
|
Function Item
|
Parameter
|
||||||
|
Display
|
LCD(132*64)
|
||||||
|
Language
|
Chinese & English & Others
|
||||||
|
AC System
|
1P2W/2P3W/3P3W/3P4W
|
||||||
|
Alternator Voltage
|
(50~280)V(ph-N)
|
||||||
|
Alternator Frequency
|
50/60Hz
|
||||||
|
Monitor Interface
|
RS485
|
||||||
|
Programmable Interface
|
LINK/RS485
|
||||||
|
Applicable Switch Type
|
PC Two-stage, PC Three-stage, CB and CC switch
|
||||||
|
DC Supply
|
DC(8-35)V
|
||||||
|
Case Dimensions(mm)
|
197*152*47
|
||||||
|
Panel Cutout(mm)
|
186*141
|
||||||
|
Operating Temp
|
(-25~+70)℃
|
||||||
